Video for Ix for a right-angle triangle case 1.
This video illustrates how to calculate Ix for right-angle case 1, where the opposite side is on the left. We use two methods: a horizontal strip and a vertical strip.
The horizontal strip is treated as the sum of the inertia of a horizontal rectangular strip about the X-axis. The vertical strip is treated as the sum of the inertia of a vertical rectangular strip about the X-axis.
You can refer to post-7 for more illustrations and to download the PDF data for more details
Timestamps:
- 0:00 – Practice problem#1: find Ix, Kx, Iy, and Ky for a given rectangular section.
- 02:58 – The steps to find the value of Ix and Kx.
- 03:49 – The steps to find the value of Iy and Ky.
This is the PDF file for the video content; you can view and download it using the button below.
The previous video is Video-8-Video for practice problem 2 on the moment of inertia.
The related post is post-7– moment of inertia for right-angle-Ix-Case-1.
The next video covers Iy for a right-angle triangle, case 1.
