Video for a product of inertia-right-angle case 2.
How can we derive an expression for the product of inertia at the intersection of the base and the Y axis at the left side of the right-angle case 2?
Two methods are used to find the value of Ixy. The first method uses a vertical strip, while the second uses a horizontal strip.
For Ixy estimation, we use a horizontal strip; the strip width is (b-x), and its height is y.
2- Since the strip height starts from the base and intersects with line AC, the y value is the same as the line AC equation y=h*x/b, for x value it will be=b*y/h.
3- the product moment of inertia due to that strip dIxy=dA*xbar*ybar), our x bar =((x+0.50*(b-x))=1/2(b+x), while ybar=y. Since we are integrating in the y direction, we will substitute for the x value as (x=b*y/h ). We integrate from x=0 to x=b, and the final answer is Ixy = h^2*b^2/8, the same value obtained using a horizontal strip.
Timestamps for the video:
- 0:00- How to derive the expression for the product of inertia for a right-angle triangle case -2? Case of a vertical strip.
- 3:10- The value of Ixy for a right-angle triangle case -2 with a vertical strip.
- 4:00- How to derive the expression for the Product of Inertia for a right-angle triangle case -2? Case of HL strip.
- 8:00- The value of Ixy for a right-angle triangle case -2 with a vertical strip.
You can view or download the PDF of the video by clicking the button.
For an external resource, the definition of the moment of inertia with solved problems, and the 2nd moment of inertia.
The previous video is 15-Video-Iy and polar moment of inertia-right angle-case 2.
The related post is post-12: Product of inertia Ixy for the right-angle case 2.
The next video is no. 17, a Video for Ixy in the CG-right-angle case 2.
