Category: Videos for the second moment of area
17-Video for Ixy at CG-right-angle case 2.
Video for Ixy at CG-right-angle case 2. using the parallel axes theorem we can derive an expression for Ixy at the Cg.
16-Video for a product of inertia-right-angle case 2.
Video for a product of inertia-right-angle case 2. two methods are used to find the product of inertia for right-angle case 2.
15-Video-Iy and polar moment of inertia-right angle-case 2.
Video-Iy and polar moment of inertia-right angle-case 2. Detailed calculations to find the value of Iy at the Cg and also the polar moment of inertia.
14-Video-Use a vl strip to get Iy for right-angle case-2.
Video-Use a vl strip to get Iy for right-angle case-2. derive the value for iy for yaxis is at the left and for the Y axis at the right.determine the radius of gyration for the two cases.
13-Video-Use a vl strip to get Ix for right-angle case-2.
Video-Use a vl strip to get Ix for right-angle case-2. Derive the expression for Ix at the Cg and estimate the radius of gyration.
12-Video for Ix for a right-angle case -2-Use Hl strip.
Video for Ix for a right-angle triangle case 2. By Using a horizontal strip we can obtain ix at the left corner and Ix at the Cg.
